Mezzanine Floor for Industrial Warehouse Storage


A steel structure mezzanine floor or entresol is a raised platform that is independent of the building structure and that is supported by steel columns.

Mezzanine floors can create additional space for a variety of different uses, such as storage space or additional office space. Warehouse mezzanine flooring is a very fast and cost-effective way to create new spaces without the expense and inconvenience of moving. A steel structural mezzanine floor utilities the overhead space in your existing premises with the minimum of disruption and in most cases without the need for planning permission. It is completely customized to the specific needs of the organization and it can be used across a variety of floor surfaces and sizes to maximize space and improve space for optimal use from the total site. A mezzanine floor can handle many different applications, which supports ranging from light storage to heavy machinery.

Mezzanine floor rack is an additional working space built on the existing site, shelf or a middle attic, in order to increase the storage space, can be built in two, three floor attic, appropriate access some light and small medium-sized pieces of goods, suitable for many kinds of large or multiple varieties and small batch of items like manual access kind of goods. Items are usually delivered by forklifts, hydraulic lifting platform or transfer to the second or the third floor, again by light car or hydraulic pallet truck to a particular location.

The mezzanine floor racks are usually supported by medium shelf shelves or heavy shelf shelves plus the floor panel (according to the total load weight of the shelf unit to decide which shelf to choose). Set up support beams under the flooring tiles. The flooring tile is usually made of cold-rolled steel, patterned steel or steel grating. It has the advantages of strong load-bearing capacity, good integrity, good load uniformity, high precision, smooth surface, easy locking, etc. There are many types to choose from, and it is easy to match the lighting system, so it is convenient to access and manage. Mezzanine-Floor-01

Feature&Advantages:

  • Versatility and flexibility to meet any storage needs;
  • The most commonly use for Palletised goods in all storage systems;
  • Low capital cost;
  • Easy to install and simple to adjust;
  • Compatible with most types of handling equipment;
  • Less storage density compared to other pallet racking systems;
  • Infinitely adjustable and offering a wide range of options and components;
  • Maximizes space use in any warehouse configuration while retaining optimum product accessibility;
  • quality guarantee 3 years;
  • More than 300 workers enable us to guarantee the delivery time, normal orders within 20days;



Product Name

Steel Structure Mezzanine Floor

Customized Specification

Rack Supported Mezzanine is available in a range of sizes and configurations. Please call or email us and we can work together to get the most cost-effective and practical solution.

Upper/Lower Rack Levels

2 levels, 3 levels, 4 levels, 5 levels

Rack Load Capacity

300KG, 500KG, 700KG, 1000KG, 1500KG per level

Catwalk/Aisle Width

800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm

Catwalk or Aisle Flooring

Load Carry Capacity

300KG, 500KG, 600KG per square meter

Raw Material

High quality cold rolling steel

Material Thickness

1.5mm, 1.8mm, 2.0mm, 2.5mm

Surface Treatment

deoil, derusting and powder coat paint finish

Mezzanine Colors

standard blue, orange and customized available

Product Accessories:

Mezzanine-Floor-05 Mezzanine-Floor-06

Product Packing:

Packing
